Performance and Capacity

The Vess A8600 and A8800 combines performance and scalable on premise storage capacity ideal for video surveillance and data-intensive workloads of large enterprises. Vess A8600 and A8800 are specially engineered for video recording and Intelligent Video Analytics (IVA) applications. Hardware options include PCI slots suitable for an additional Intel Xeon CPU (dual CPU option); or a GPU card can be used for video analytics or other processor intensive applications.

PROMISE proprietary SMARTBOOST™ and PromiseRAID technology ensures robust, high-performance storage for video recording without frame drop; it has proven itself in the industry in thousands of large-scale deployments worldwide.

Storage capacity of 320TB for the Vess A8600 and 480TB for the Vess A8800 plus huge scale up potential (320TB / 480TB) provides flexibility for future growth. Capacity can be seamlessly added to an existing setup as needed using Vess R3000/J3000 external storage hardware connected via iSCSI interface.

  • Intelligent Video Analytics
  • Intel Xeon Scalable CPU
  • Expansion-Ready

Simplified Management and Reduced Complexity

Vess A8600 and A8800 simplifies management of the surveillance network for daily operation. Integration of recorder and storage servers provides a total video surveillance solution combining VMS software and external storage. The legacy of the Vess A-Series is fully expressed in the Vess A8600 and A8800 with features integrated into the most popular VMS vendors. The systems are easy to setup, manage and maintain, greatly reducing the burden upon already overloaded IT staff. Once in place, little active management is needed and for many VMS platforms, storage system status is monitored directly the VMS user interface using a special plug-in designed for the particular VMS. Management software supports SNMPv2 as well as SNMP v3 for additional security.

Modular hardware design enables quick replacement in the field for components such as hard drives and power supplies plus One Plug Auto Service (OPAS) for fast diagnosis of any problems by PROMISE tech support staff available 24/7 online or via phone.

Reduced Power Consumption and Green Technology

PROMISE is committed to creating products that are power efficient and reduce harmful waste in the manufacturing. The new Vess A8600/A8800 continues in this effort with hot-swappable power supply modules and green design concepts (GreenBoost™ technology) incorporated into the hardware engineering to reduce power consumption, noise and thermal output.

Specifications

Model
Vess A8600
Vess A8800

General Information
Camera Range¹
170
200
Form Factor
3U, 19" Rackmount
4U, 19" Rackmount
Number of Drives
16 Drives
24 Drives
Drive Type
Hot Swappable 3.5" Enterprise SATA HDD 6Gbs. Optional 2.5" Enterprise SATA SSD
Internal Storage
M.2 PCIe NVMe SSD 256GB (Standard) or M.2 256GBx2 OS RAID (Optional)
System Processor
2nd Generation Intel® Xeon® Scalable Processors
System Memory
2 x 16GB DDR4 Default (Max 768GB)
Storage Expansion
Optional PROMISE Vess R and Vess J series via iSCSI
Show More
Interface
NIC Port
4 x Gigabit Ethernet (Optional accessory: Dual port 10Gbps SFP+ NIC)
IPMI Port
1 x Dedicated IPMI Gigabit Ethernet
USB Port
2 x USB 3.0
PCI Express Port
"4 x PCIe3.0 x16
1 x PCIe3.0 x8 (available only when OS RAID card is not present)"
Graphic Interface
1x D-sub VGA
Audio I/O
3 x 3.5mm Audio Jack
Graphic Card Support
Supports Nvidia Pascal, Turing, Ampere, Ada Lovelace and Hopper Arch. GPUs

4 x 350mm (L) * 111mm(H) * single slot
2 x 350mm (L) * 111mm(H) * dual slots
4 x 350mm (L) * 155mm(H) * single slot
2 x 350mm (L) * 155mm(H) * dual slots
RAID Operational Feature
RAID Level
0, 1, 1E, 3, 5, 6, 10 (0+1), 30, 50, 60 (Any combination can be configured simultaneously)
Hot Spares
Multiple global or dedicated hot-spare drives with revertible option
Software
OS Supported (64-bit)
Windows 10, Windows Server 2019, Windows Server 2022, Ubuntu
Management Tools
Graphical UI/SNMP via Ethernet, CLI via Ethernet or Graphics, OPAS Service via USB, SDK or API for Integration
Optimization Technologies
SMARTBOOST™ Storage for Video Surveillance optimization
Event Notification
Email, SNMP (V1/V2/V3), Buzzer, LEDs
System Information
AC Input
100 ~ 240 VAC, 60 ~ 50Hz
Current (Maximum)
<15A @ 100-127Vac @full load / <10A @ 200-240Vac/160-340Vdc @full load
Power Supply
Hot Swappable 80 PLUS Platinum 1200W Redundant Power Supply (80 PLUS Titanium 1300W available for Europe)
Temperature
5° ~ 40°C (-40° ~ 60°C non-operational)
Dimensions (H x W x D)
131 x 482 x 665 mm / 5.16" x 18.98" x 26.18"
175 x 482 x 665 mm / 6.89" x 18.98" x 26.18"
Weight
W/o HDD ~21.50kg (~ 47.40 lbs)
W/ HDD: ~33.50kg (~ 73.75 lbs)
W/o HDD ~25.50kg (~ 55.25 lbs)
W/ HDD: ~43.00kg (~ 94.75 lbs)
Warranty and Support
Warranty
3-years standard warranty, optional extended warranty, and on-site parts replacement program (PROMISE ServicePlus) available.
Support
24/7 PROMISE eSupport Portal (support.promise.com), optional 24/7 phone and email support available.
1. The Camera range is suggested value, tested in PROMISE lab under specific test scenario. For specific requirement, please consult with PROMISE sales representative.
*All specifications and descriptions provided herein may be different from the actual specifications and descriptions of the product.
